Sherlo 403MHz Fixed Panic Alarm Panel Code-Hopping

R 914.68

Self-contained wireless panic system with power supply. Designed to be wired to a static hardwired panic button as well as work with Remote panic buttons. When a Panic is activated the unit will trigger the 3 Minute siren output as well as the Radio output and a Latching Strobe output. All activations can be reset via either the Remote control or the Hardwired Panic button. Battery not included and remote sold separately.

Features

    • Microprocessor Controlled charging output
    • Low battery switch off at 10V DC
    • Buzzer tones on battery low and AC Fail
    • Resettable Fuse protection on output
    • Fuse protection on AC input
    • ABS Plastic enclosure

    Specifications

    • Input Voltage Range: 110V ~ 230V AC 50Hz
    • Output Voltage: 13V ~ 14.4V Adjustable
    • Max Current output: 3.2A DC @ 14V
    • Relay contact rating: 10A
    • AC Fail output rating: 140mA Positive switching
    • Operating temp: -3°C to 60°C
    • Dimensions (L x B x H): 200 x 180 x 87mm
    • Gross Weight: 0.895Kg

    Applications

    • Office panic
    • Shop panic
    • Home panic
    • Factory panic
    • Guard house panic

    FPP
